Computational Geometry

Chip Bell

Vectors

Can represents a group of real numbers (not useful for us)
Can represent a position in space (useful for us)
Can represent something with magnitude and direction (useful for us)

A Position in space (aka Cartesian coordinates)

\[ (x, y) \]

Something with Magnitude and direction (aka Polar coordinates)

\[ (r, \theta) \]

Converting from Cartesian to Polar

\[ r = \sqrt{x^2 + y^2} \]

\[ \theta = \tan^{-1}{\frac{y}{x}} \]

Converting from Polar to Cartesian

\[ x = r\cos{\theta} \]

\[ y = r\sin{\theta} \]

Vector Operations

Addition

\[ (x_1, y_1) + (x_2, y_2) = (x_1 + x_2, y_1 + y_2) \]

Basically add up corresponding elements)
Essentially like saying "Move $x_1$ left, $y_1$ north. From there, move $x_2$ left, then $y_2$ north"
Subtraction works the same way

Dot Product

\[ (x_1, y_1) \cdot (x_2, y_2) = x_1 x_2 + y_1 y_2 \]

Measures how much "vectors have in common"
Can provide length of a vector: $\sqrt{v \cdot v}$ is the length of the vector $v$
Can provide angle between two vectors (later)

Cross Product

\[ (x_1, y_1) \times (x_2, y_2) = x_1y_2 - y_1x_2 \]

Can provided angle between vectors
Can be used to provide angle
Can be used for calculating "turn direction"
Pay attention to the subtraction!
Pay attention to the combination of $x$'s and $y$'s

Rotation

Given an angle $\theta$ \[ R(v, \theta) = (v_x\cos{\theta} + v_y\sin{\theta}, v_x\sin{\theta} + v_y\cos{\theta}) \]

Rotates a vector around the origin. To rotate around a vector $w$: \[ R_w(v, \theta) = w + R(v - w, \theta) \]
Pay attention to the comma!
Pay attention to the signs!

Implementations

Python


class Vector:
    def __init__(self, x, y):
        self.x = x
        self.y = y

    def add(self, other):
        return Vector(self.x + other.x, self.y + other.y)

    def negate(self):
        return Vector(-self.x, -self.y)

    def subtract(self, other):
        return self.add(other.negate())

    def dot(self, other):
        return self.x * other.x + self.y * other.y

    def magnitude(self):
        return (self.dot(self)) ** 0.5

    def cross(self, other):
        return self.x * other.y - self.y * other.x

    def __repr__(self):
        return "{0},{1}".format(self.x, self.y)

v = Vector(1, 0)
w = Vector(0, 1)

print(v.dot(w))
print(v.cross(w))
print(v.add(w))
print(v.negate())
print(v.add(w).magnitude())

Java


public class Vector {
    protected double x;
    protected double y;

    public Vector(double x, double y) {
        this.x = x;
        this.y = y;
    }

    public Vector add(Vector other) {
        return new Vector(this.x + other.x, this.y + other.y);
    }

    public Vector negate() {
        return new Vector(-this.x, -this.y);
    }

    public Vector subtract(Vector other) {
        return this.add(other.negate());
    }

    public double dot(Vector other) {
        return this.x * other.x + this.y * other.y;
    }

    public double magnitude() {
        return Math.sqrt(this.dot(this));
    }

    public double cross(Vector other) {
        return this.x * other.y - this.y * other.x;
    }

    public String toString() {
        return "" + this.x + "," + this.y;
    }

    public static void main(String[] args) {
        Vector v = new Vector(1, 0);
        Vector w = new Vector(0, 1);

        System.out.println(v.dot(w));
        System.out.println(v.cross(w));
        System.out.println(v.add(w));
        System.out.println(v.negate());
        System.out.println(v.add(w).magnitude());
    }
}

Basic Applications

Length of Vector

\[ || v || = \sqrt{v \cdot v } \]

Distance Between Vectors

It's the magnitude of the difference \[ || w - v || = \sqrt{ (w - v) \cdot (w - v) } \]

Angle Between Two Vectors

\[ \theta = \cos^{-1} \frac{a \cdot b }{ |a| |b| } \]

Be mindful of the range of $cos^-1$

Area of Parallelogram

\[ |v \times w| \]

Note that you can divide in two to get the area of a triangle!

More Complex Applications

Area of a Polygon

We can extend the area notion with the cross product to get the area of a polygon

Given a polygon with $n$ points $(x_0, y_0), (x_1, y_1), ..., (x_{n-1}, y_{n-1})$, we can use the Shoelace formula to calculate area: \[ A = \frac{1}{2} \sum_{i=0}^{n-1} p_i \times p_{i+1} \]

Note that $p_i = (x_i, y_i)$ and $p_n = p_0$
This value can be negative, so take the absolute value

Convex Hull

Finds the smallest convex polygon that contains a set of points

Jarvis March

Graham Scan

Line Segment Intersection

Given two line segments: \[ L_1(t) = p_1 + d_1t, 0 \le t \le 1 \] and \[ L_2(t) = p_2 + d_2t, 0 \le t \le 1 \]

We can find where the intersect by clever usage of the dot product and cross product. Figure it out yourself!

Many, Many More

Example Problems

Welding

Premise is to count number of ways to place arc-shaped pieces of metal
Being able to move along an arc requires lots of rotation vectors!
Solution here

Robots

You've got a Martian robot with two 1-foot radius wheels
You're given a series of rotation commands for each wheel
Each rotation command has a speed and duration associated with it
Calculate the location of the robot after the commands are completed
Requires you to calculate the turn radius at each moment and do similar arc math as before
Solution here

Convex Hull

Requires you to calculate the points contained in the convex hull of a set
The convex hull is the smallest convex polygon that contains a set of points (rubber band around nails)
Basic solution is to calculate the convex hull, and then keep only points not in the convex hull
Pretty much self-explanatory: Implement Jarvis March...
Problem outlines an algorithm, but the Graham Scan is easier to write and understand in a competition
Really nice Convex Hull implementations here (using the Monotone Chain Algorithm). I suggest you copy, bring to the contest, and just modify for the problem!

Star Simulations

Given a series of points, how many are less than $k$ units away from each other?
Classic spatial indexing problem
Solution here, using simple but clever spatial indexing
